Icom IC-i7410 - Memory Clearing

64
6
FUNCTIONS FOR TRANSMIT
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
■ Speech Compressor
(Mode: SSB )
The Speech Compressor function increases average
RF output power, improving signal strength and read-
ability.
q Push [SSB] to select the USB or LSB mode.
w Rotate the [MIC] control to adjust the microphone
gain so the ALC meter reads within the ALC zone,
whether or not you speak softly or loudly.
e P ush [COMP] to turn ON the Speech Compressor
function.
 •“COMP”appears.
r While speaking into the microphone at your normal
voice level, rotate the [COMP] control to adjust the
compressor level so the COMP meter reads within
the COMP zone.
 •Holddown[F-3]for1secondtoresettothedefaultset-
ting, if desired.
When the COMP meter peaks above the COMP
level zone, your transmitted voice may be dis-
torted.
■ Transmit lter width selection
(Mode: SSB )
The transmit filter width for the SSB mode can be set
to Wide, Mid or Narrow.
q Push [SSB] to select the USB or LSB mode.
w P ush [MENU] to display the “M1” screen (Menu
1), then hold down [TBW](F-4) for 1 second, one
or more times, to select a Wide, Mid or Narrow
transmission passband width.
 •Push[TBW](F-4)momentarilytodisplaytheselected
TX filter width for approximately 1 second.
 •Thefollowingltersarespeciedasthedefaults.Each
of the filter widths can be set in the Tone Control Set
mode. (pp. 90, 91)
- WIDE : 100 Hz to 2900 Hz
- MID : 300 Hz to 2700 Hz
- NAR : 500 Hz to 2500 Hz
Hold down
The selected transmit filter width is
displayed for approximately 1 second.
[SSB]
[COMP][COMP] control
[MIC] control
Appears
COMP level zone
COMP meter
AGC TBW SCP
M1
[SSB] [TBW]
AGC TBW SCP
M1
AGC TBW SCP
M1
TBW WIDE
