10
USB Audio SQL 38. (Default: OFF(OPEN))
Select whether or not to output the audio from the
[USB] connector on the rear panel, according to the
squelch state.
The same audio signals are sent from the [USB] con-
nector and the [ACC] sockets.
- The beep tones and the voice synthesizer announce-
ments are not sent.
- The received audio output level cannot be adjusted
with the [AF] control.
•OFF(OPEN) :Thereceivedaudioisalwayssent,
regardless of the squelch state.
•ON :Thereceivedaudioissentwhenthe
squelch is open.
USB MOD Level 39. (Default: 50%)
Set the input modulation level of the [USB] connector
tobetween0%and100%in1%steps.
DATA OFF MOD 40. (Default: MIC,ACC)
Select the desired connector(s) for data modulation
input in the data OFF mode.
•MIC :Usethesignalsfrom[MIC].
•ACC :Usethesignalsfrom[ACC](pin11).
•MIC,ACC :Usethesignalsfrom[MIC]and[ACC]
(pin 11).
•USB :Usethesignalsfrom[USB].
DATA MOD 41. (Default: ACC)
Select the desired connector(s) for data modulation
input in the data mode.
•MIC :Usethesignalsfrom[MIC].
•ACC :Usethesignalsfrom[ACC](pin11).
•MIC,ACC :Usethesignalsfrom[MIC]and[ACC]
(pin 11).
•USB :Usethesignalsfrom[USB].
CI-V Baud Rate 42. (Default: Auto)
Set the CI-V data transfer rate between 300, 1200,
4800, 9600, 19200 bps and “Auto.”
When “Auto” is selected, the baud rate is automatically
set according to the data rate of the connected con-
troller.
CI-V Address 43. (Default: 80h)
To distinguish equipment, each CI-V transceiver has
its own Icom standard address in hexadecimal code.
The IC-7410’s address is 80h.
When 2 or more IC-7410’s are connected to an op-
tional CT-17
c i -v level converter, rotate [DIAL] to se-
lect a different address for each IC-7410; the range is
01h to DFh.
CI-V Transceive 44. (Default: ON)
Turn the transceive operation using the CI-V system
ON or OFF.
When this item is set to ON, changing the frequency,
operating mode, etc. on the IC-7410 automatically
changes those settings on other Icom HF transceivers
or receivers, and vice versa.
•OFF:TransceiveoperationOFF
•ON :TransceiveoperationON
USB Serial Func 45. (Default: CI-V)
Select the function for the USB port on the rear panel.
•CI-V :UsedtosendCI-Vcommands
.
•RTTY :IntheRTTYmode,usedtosendRTTYde-
coded signal.
RTTY Decode Baud 46. (Default: 9600)
Set the RTTY decode monitor speed to 300, 1200,
4800, 9600 or 19200 bps.
Calibration Marker 47. (Default: OFF)
Use as a simple frequency check of the transceiver.
See page 98 for calibration procedure.
NOTE: Turn OFF the calibration marker after check-
ing the frequency of the transceiver.
•OFF:CalibrationmarkerOFF
•ON :CalibrationmarkerON
REF Adjust 48.
During frequency calibration, set the internal refer-
encefrequencytobetween0%and100%rangein1%
steps.
NOTE: The default setting is different for each
transceiver.
■ Set mode description (Continued)
