28
3
BASIC OPERATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
D Auto Tuning Step function
When you rotate [DIAL] rapidly, the tuning speed can
automatically accelerate, depending on the “MAIN
DIAL Auto TS” setting in the Set mode.
q Hold down [MENU] for 1 second to enter the Set
mode.
w Push [Y](F-1) or [Z](F-2) to select “MAIN DIAL
Auto TS.”
e Rotate [DIAL] to select the HIGH or LOW tuning
speed acceleration, or to turn OFF the function.
•HIGH:Whenthe tuning step is setto1 kHzor
smaller steps, the tuning speed is approxi-
mately five times faster.
When the tuning step is set to 5 kHz or
larger steps, the tuning speed is approxi-
mately two times faster. (default)
•LOW:Approximatelytwotimesfaster.
•OFF :TurnsthefunctionOFF.
•Holddown[F-3]for1secondtoresettothedefaultset-
ting, if desired.
r Push [MENU] to save, and exit the Set mode.
[][]
[DIAL][MENU]
HIGH (default)
Ù 26 Ú HIGH
SET MAIN DIAL Auto TS
D About the 5 MHz frequency band operation (only USA version)
Operation on the 5 MHz band is allowed on 5 discrete
frequencies and must adhere to the following:
•TheUSBmode
•Maximumof50wattsERP(Effective Radiated Power)
•2.8kHzbandwidth
It’s your responsibility to set all controls so that trans-
mission in this band meets the stringent conditions
under which amateur operations may use these fre-
quencies.
NOTE: We recommend that you store these fre-
quencies, mode and filter settings into memory
channels for easy recall.
* The FCC specifies center frequencies on the
5 MHz band. However, the transceiver displays car-
rier frequency. Therefore, tune the transceiver to
1.5 kHz below the specified FCC channel center
frequency.
Transceiver Displayed
Frequency*
FCC Channel
Center Frequency*
5.33050 MHz 5.33200 MHz
5.34650 MHz 5.34800 MHz
5.36650 MHz 5.36800 MHz
5.37150 MHz 5.37300 MHz
5.40350 MHz 5.40500 MHz
To assist you in operating the 5 MHz band within the
rules specified by the FCC, transmission is illegal on
any 5 MHz band frequency other than the five fre-
quencies shown in the table above.
