Icom IC-i7410 User Manual

109
SPECIFICATIONS
15
■ General
•Frequencycoverage :(unit:MHz)
Receive
0.030–60.000*
1
*
2
Transmit
1.800–1.999*
2
, 3.500–3.999*
2
,
5.33050*
3
, 5.34650*
3
, 5.36650*
3
,
5.37150*
3
, 5.40350*
3
,
7.000–7.300*
2
, 10.100–10.150*
2
,
14.000–14.350*
2
, 18.068–18.168*
2
,
21.000–21.450*
2
, 24.890–24.990*
2
,
28.000–29.700*
2
, 50.000–54.000*
2
*
1
Some frequency bands are not guaranteed.
*
2
Depending on version. *
3
Only USA version.
•Mode :USB,LSB,CW,RTTY,AM,FM
•No.ofmemorychannels:101CH
( 99 regular, 2 scan edges)
•Antennaimpedance :50ø ( at Antenna Tuner OFF)
•Antennaconnectortype :SO-239× 2
•
Usable temperature range : 0˚C to +50˚C (+32˚F to +122˚F)
•Frequencystability :Lessthan±0.5ppm5min.after
power ON.
(0˚C to +50˚C; +32˚F
to +122˚F)
•Frequencyresolution :1Hz
•Powersupply :
13.8VDC±15%(negative ground)
•Powerconsumption
Transmit
Max. power : 23.0 A
Receive
Standby : 2.2 A
Max. audio : 3.0 A
•Dimensions :315(W)× 116(H) × 343(D) mm
(projections not included) 12.4(W) × 4.57(H) × 13.5(D) in
•Weight(approx.) :10.2kg;22.4lb
•ACCconnector :13-pin
•CI-Vconnector :2-conductor3.5(d)mm(
1
⁄8″)
■ Transmitter
•Outputpower(continuously adjustable)
SSB/CW/RTTY/FM : 2 to 100 W
AM : 2 to 27 W*
(*Carrier power)
(at 13.8 V DC/+25˚C)
•Modulationsystem
SSB : Digital PSN modulation
AM : Digital Low power modulation
FM : Digital Phase modulation
•Spuriousemission
HF bands : Less than –50 dB
50 MHz band : Less than –63 dB
•Carriersuppression :Morethan40dB
•Unwantedsideband
suppression : More than 55 dB
•∂TX variable range : ±9.999 kHz
•Microphoneconnector :8-pinconnector
(600 ø)
•ELEC-KEYconnector :3-conductor6.35(d)mm(
1
⁄4″)
•KEYconnector :3-conductor6.35(d)mm(
1
⁄4″)
•SENDconnector :Phonojack
(RCA)
•ALCconnector :Phonojack(RCA)
