Icom IC-i7410 User Manual

36
4
RECEIVE AND TRANSMIT
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
■ Operating CW
q Select the desired band. (p. 25)
w Push [CW] to select the CW mode.
 •Pushing[CW]alternatelyselectsCWorCWreverse
mode.
e Rotate [DIAL] to tune a desired signal.
 •TheS-meterindicatesthereceivedsignalstrength.
 •Thetuningstepcanbechangedinthetuningsteppro-
gram mode. (p. 27)
r Rotate the [AF] control to adjust the audio to a com-
fortable listening level.
t Push [TRANSMIT] to transmit.
 •TheTXindicatorlightsred.
y Use the electric keyer or paddle to key your CW
signals.
 •ThePometerindicatestransmittedCWoutputpower.
u Push [TRANSMIT] again to receive.
AGC 1/4 KEY SCP
M1
[DIAL][CW][AF]
[TRANSMIT] TX indicator
“CW” or “CW-R” appears
Convenient Receive functions
•Preampandattenuator(p.55)
•TwinPBT(passbandtuning)(p.59)
•AGC(AutoGainControl)(p.56)
•NoiseBlanker(p.60)
•NoiseReduction(p.61)
•ManualNotchlter(p.61)
•CWpitchcontrol(p.37)
•¼ function (p. 27)
Convenient Transmit functions
•Break-infunction(p.63)
•Keyingspeedsetting(p.37)
•Memorykeyer(p.38)
