IEI Technology WSB-9454 User Manual

WSB-9454 CPU Card
Page 85
Figure 4-9: SATA Drive Cable Connection
Step 3: Connect the connector on the other end of the cable to the connector at the back
of the SATA drive (Figure 4-10).
Step 4: Connect the SATA power connector to the back of the SATA drive (Figure 4-10).
Step 0:

IEI Technology WSB-9454 Specifications

General

Brand	IEI Technology
Model	WSB-9454
Category	Motherboard
Language	English
