IEI Technology WSB-9454 User Manual

WSB-9454 CPU Card
Page 51
PIN DESCRIPTION
1 VCC
2 NC
3 SIN1_IRRX
4 GND
5 SOUT1_IRTX
Table 3-13: IrDA Interface Connector Pinouts
3.2.11 Keyboard Connector
CN Label: KB1
CN Type:
4-pin wafer
CN Location: See Figure 3-12
CN Pinouts: See Table 3-14
For alternative application, a keyboard pin header connector is also available on board.
This connector requires a special adapter cable.
