WSB-9454 CPU Card
Page 35
Figure 3-4: Backplane to Mainboard Power Connector Location
PIN NO. DESCRIPTION
1
GND
2
ATX -ON
3
5VSB
Table 3-6: Backplane to Mainboard Power Pinouts
