WSB-9454 CPU Card

Page 31

Figure 3-2: ATX–12V Connector Location

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 GND 2 GND

3 +12V 4 +12V

Table 3-4: ATX–12V Connector Pinouts
