WSB-9454 CPU Card
Page 89
4.6 On-board Jumper
NOTE:
A jumper is a metal bridge that is
used to close an electrical circuit. It
consists of two metal pins and a
small metal clip (often protected by a
plastic cover) that slides over the pins
to connect them. To
CLOSE/SHORT a jumper means
connecting the pins of the jumper
with the plastic clip and to OPEN a
jumper means removing the plastic
clip from a jumper.
Figure 4-13 Jumper
The CPU card one on-board jumper. The jumper is described in Table 4-2.
Label Connector Type
J_CMOS1 CMOS state setting 3-pin header
Table 4-2: On-board Jumpers
