IEI Technology WSB-9454 User Manual

WSB-9454 CPU Card
Page 29
SATA1
SATA2
SATA3
SATA4
Serial ATA Connectors
7-pin SATA connector
USB01
USB23
USB45
USB Connectors
8-pin header
Table 3-1: Peripheral Interface Connectors
3.1.3 External Peripheral Interface Connectors
Table 3-2 lists the external peripheral interface connectors on the WSB-9454. Detailed
descriptions of these connectors can be found in Section 3.3.
Connector Type Label
Ethernet connectors RJ-45 connector LAN1
LAN2
Keyboard/mouse connector MINI-DIN connector KB_MS1
USB connector USB 2.0 connector USB_C6
VGA connector HD-D-sub 15 female connector VGA1
Table 3-2: External Peripheral Interface Connectors

IEI Technology WSB-9454 Specifications

General

Brand	IEI Technology
Model	WSB-9454
Category	Motherboard
Language	English
