IEI Technology WSB-9454 User Manual

WSB-9454 CPU Card
Page 46
FUNCTION PIN DESCRIPTION FUNCTION PIN DESCRIPTION
1
PWR_LED+
2
SPKR+
3
N/C
4
N/C
Power LED
5
PWR_LED-
6
N/C
7
PWR_BTN+
Speaker
8
SPKR-
PWRBTN
9
PWR_BTN-
RESET 10
N/C
11
HDD_LED+
12
RESET+
HDDLED
13
HDD_LED-
14
RESET-
Table 3-11: Front Panel Connector Location
3.2.9 IDE Connector
CN Label: PIDE1
CN Type:
40-pin box header
CN Location: See Figure 3-10
CN Pinouts: See Table 3-12
One IDE connector provides connectivity for two IDE devices.
