WSB-9454 CPU Card
Page 28
3.1.2 Peripheral Interface Connectors
Table 3-1 lists the peripheral interface connectors on the WSB-9454 CPU card. Detailed
descriptions of these connectors can be found in Section 3.2.
Label Connector Type
CPU12V1 ATX-12V CPU Power Source 4-pin terminal block
J_AUDIO1 Audio Module Connector 9-pin header
ATXCTL1 Backplane to Mainboard Power Connector 3-pin wafer connector
CPU_FAN1 CPU Fan Connector 4-pin wafer connector
DIO1 Digital I/O Connector 10-pin header
DVI1 Digital Visual Interface Connector 25-pin header
FDD1 FDD Connector 34-pin box header
F_PANEL1 Front Panel Connector 14-pin header
PIDE1 IDE Connector 40-pin box header
IR1 IrDA Infrared Interface Connector 5-pin header
KB1 Keyboard Connector 4-pin wafer connector
LPT1 Parallel Port Connector 25-pin box header
COM1
COM2
RS-232 Serial Port Connectors
10-pin box header
