WSB-9454 CPU Card
Page 30
3.1.4 On-board Jumper
Table 3-3 lists the on-board jumper. Detailed descriptions of this jumper can be found in
Section 4.6.
Label Connector Type
J_CMOS1 CMOS state setting 3-pin header
Table 3-3: On-board Jumper
3.2 Internal Peripheral Connectors
Internal peripheral connectors are found on the CPU card and are only accessible when
the CPU card is outside of the chassis. This section has complete descriptions of all the
internal peripheral connectors on the WSB-9454 CPU card.
3.2.1 ATX-12V Power Source Connector
CN Label: CPU12V1
CN Type:
4-pin terminal block
CN Location: See Figure 3-2
CN Pinouts: See Table 3-4
This connector supports the ATX-12V power supply.
