WSB-9454 CPU Card
Page 65
PIN NO. DESCRIPTION
1 Keyboard Data
2 Mouse Data
3 GND
4 VCC
5 Keyboard Clock
6 Mouse Clock
Table 3-21: Mini-DIN 6 PS/2 Connector
3.3.3 USB Connector
CN Label: USB_C6
CN Type:
USB port
CN Location: See Figure 3-17 (labeled number 3)
CN Pinouts: See Table 3-22
The WSB-9454 has one rear panel USB port. This port connects to both USB 2.0 and
USB 1.1 devices.
PIN NO. DESCRIPTION
1 VCC
2 DATA-
3 DATA+
4 GROUND
Table 3-22: USB Port Pinouts
