WSB-9454 CPU Card
Page 22
2.18 Power Consumption
Table 2-2 shows the power consumption parameters for the WSB-9454 CPU card when a
3GHz Intel
®
Pentium
®
4 processor is running with four 1GB, DDR2 533MHz SDRAM
memory modules.
Voltage Current
5V 6.75A
+12V 7.24A
Table 2-2: Power Consumption
2.19 Packaged Contents and Optional Accessory Items
2.19.1 Package Contents
When you unpack the WSB-9454 CPU card you should find the following components.
1 x WSB-9454 single board computer
1 x Mini jumper pack
1 x ATA 66/100 flat cable
1 x Dual RS-232 cable
2 x SATA cables
1 x SATA power cable
1 x Keyboard/ PS2 mouse Y cable
1 x USB cable
1 x Utility CD
1 x QIG (quick installation guide)
2.19.2 Special Items
The following additional items are shipped with the WSB-9454DVI-R10 CPU card models.
2 x SATA cables
1 x SATA power cable
