WSB-9454 CPU Card
Page 99
Processor: Displays auto-detected CPU specifications
o Type: Names the currently installed processor
o Speed: Lists the processor speed
o Count: The number of CPUs on the motherboard
System Memory: Displays the auto-detected system memory.
o Size: Lists memory size
The System Overview field also has two user configurable fields:
System Time [xx:xx:xx]: The system time is set here.
System Date [Day xx/xx/xxxx]: The system date is set here.
5.3 Advanced
The Advanced menu (BIOS Menu 2) allows access to the CPU and peripheral device
configuration options through the following sub-menus:
WARNING:
Setting the wrong values in the sections below may cause the system
to malfunction. Make sure that the settings made are compatible with
the hardware.
CPU Configuration (see Section 5.3.1)
IDE Configuration (see Section 5.3.2)
Floppy Configuration (see Section 5.3.3)
SuperIO Configuration (see Section 5.3.4)
Hardware Health Configuration (see Section 5.3.5)
ACPI Configuration (see Section 5.3.6)
APM Configuration (see Section 5.3.7)
MPS Configuration (see Section 5.3.8)
USB Configuration (see Section 5.3.9)
