Inficon Cygnus 2

9 - 16
Cygnus 2 Operating Manual
49
(0x31)
Channel 1 Graph
Scale
0/ 9/ 8 Encode 0 = Power 1 = ±0.1 Å/s
2 = ±0.5 Å/s 3 = ±1 Å/s
4 = ±2 Å/s 5 = ±3 Å/s
6 = ±5 Å/s 7 = ±10 Å/s
8 = ±20 Å/s 9 = ±50 Å/s
50
(0x32)
Channel 2 Graph
Scale
0/ 9/ 8 Encode 0 = Power 1 = ±0.1 Å/s
2 = ±0.5 Å/s 3 = ±1 Å/s
4 = ±2 Å/s 5 = ±3 Å/s
6 = ±5 Å/s 7 = ±10 Å/s
8 = ±20 Å/s 9 = ±50 Å/s
51
(0x33)
Channel 3 Graph
Scale
0/ 9/ 8 Encode 0 = Power 1 = ±0.1 Å/s
2 = ±0.5 Å/s 3 = ±1 Å/s
4 = ±2 Å/s 5 = ±3 Å/s
6 = ±5 Å/s 7 = ±10 Å/s
8 = ±20 Å/s 9 = ±50 Å/s
52
(0x34)
Channel 4 Graph
Scale
0/ 9/ 8 Encode 0 = Power 1 = ±0.1 Å/s
2 = ±0.5 Å/s 3 = ±1 Å/s
4 = ±2 Å/s 5 = ±3 Å/s
6 = ±5 Å/s 7 = ±10 Å/s
8 = ±20 Å/s 9 = ±50 Å/s
53
(0x35)
Channel 5 Graph
Scale
0/ 9/ 8 Encode 0 = Power 1 = ±0.1 Å/s
2 = ±0.5 Å/s 3 = ±1 Å/s
4 = ±2 Å/s 5 = ±3 Å/s
6 = ±5 Å/s 7 = ±10 Å/s
8 = ±20 Å/s 9 = ±50 Å/s
54
(0x36)
Channel 6 Graph
Scale
0/ 9/ 8 Encode 0 = Power 1 = ±0.1 Å/s
2 = ±0.5 Å/s 3 = ±1 Å/s
4 = ±2 Å/s 5 = ±3 Å/s
6 = ±5 Å/s 7 = ±10 Å/s
8 = ±20 Å/s 9 = ±50 Å/s
Table 9-5 General parameters (continued)
QG
&
UG
Cmnd
ID
Name
(Units)
Range:
Low
Limit/
High
Limit/
Default
Data Type
Notes
Update Restrictions
and Display Notes
