Innova MATRIX MK II+ User Manual

Innova – Matrix MK II+
Operation and Maintenance Manual
Date
12.12.2017
Page
11 of 74
Project No.:
604653
Document No.:
MAN-000015294
Rev.
5
P.O. BOX 390 Tel.: +47 51 96 17 00 post@innova.no
4067 Stavanger, Norway Fax.: +47 51 96 17 01 www.innova.no
3.3 Connecting external equipment
Before external equipment is connected, some planning is recommended to ensure optimal use of
the available data channels.
The system provides the following connectors and data channels:
Identifier
Connector type
Signals
Power
C1
Seacon 5506-2021-E
• Ethernet (1 Gbps)
• PECL (optional)
• 24VDC (6A)
• 48VDC (6A)
Software
switchable
C2
Seacon 5506-2021-E
• Ethernet (1 Gbps)
• PECL (optional)
• 24VDC (6A)
• 48VDC (6A)
Software
switchable
C3
Seacon 5506-2021-E
• Ethernet (2x
100Mbps)
• PECL (optional)
• RS232/RS485
• 5V TTL (PPS)
• 24VDC (6A)
• 48VDC (3A)
Hardware
switchable.
24VDC is
standard.
C4
Seacon MINL-5515-75Ω
Seacon 5506-1508 (Optional)
• HD-SDI
• Analog Video
(optional)
• RS232
• 24VDC (2A)
C5
Seacon MINL-5515-75Ω
Seacon 5506-1508 (Optional)
• HD-SDI
• Analog Video
(optional)
• RS232
• 24VDC (2A)
C6
Seacon MINL-5515-75Ω
Seacon 5506-1508 (Optional)
• HD-SDI
• Analog Video
(optional)
• RS232
• 24VDC (2A)
C7
Seacon MCBH8F
• RS232
• 24VDC (2A)
C8
Seacon MCBH8F
• RS232
• 24VDC (2A)
C9
Seacon MCBH8F
• Ethernet (100Mbps)
• TTL (Same as C10)
• 24VDC (2A)
C10
Seacon MCBH8F
• RS232
• TTL (Same as C9)
• 24VDC (2A)
C11
Seacon MCBH8F
• RS232/RS485
• 24VDC (2A)
C12
Seacon MCBH6F
• RS232
• 110/230VAC
(Depending on
input
power)(3,15A)
C13
Seacon MCBH8F
• RS232/RS485
• 24VDC (2A)
C14
Seacon MCBH8F
• RS232/RS485
• 24VDC (2A)

Innova MATRIX MK II+ Specifications

General

Brand	Innova
Model	MATRIX MK II+
Category	Diagnostic Equipment
Language	English
