6.19.2 Topside
C12 RX LED
C12 TX LED
C12 RS232
RS232 Interface
RJ-45(12)
Pin
Function
1
N/C
2
N/C
3
N/C
4
RS232 - 0V
5
RS232 – RX
(Downlink)
6
RS232 – TX
(Uplink)
7
N/C
8
N/C
