6.3 FIBRE –Fibre Optical connector (Optional)
Seacon OPT-G-4(2SM,2MM)-BCR
PIN
FUNCTION
1
Topside Comms (SM)
2
Spare (SM)
3
Spare (MM)
4
Spare (MM)
Recommended mates for Seacon OPT-G-4: Seacon OPT-G-4-CCP
In the event of damage to the main fibre the spare fibre #2 can be
connected. Please contact Innova for details.
Optional: If the matrix system is ordered as a Multimode system the main
fibre will be #3.
