Fibre adapter interface details (5500-20XX)
E – MIN (inches) : 0,625
F – TYPICAL (inches) : 0,375
G – diameter (inches) : 0,77
H – diameter (inches) : 2,33
I – (inches) : 0,625
J – (inches) : 1,25
