Innova – Matrix MK II+
Operation and Maintenance Manual
Date
12.12.2017
Page
24 of 74
Project No.:
604653
Document No.:
MAN-000015294
Rev.
5
P.O. BOX 390 Tel.: +47 51 96 17 00 post@innova.no
4067 Stavanger, Norway Fax.: +47 51 96 17 01 www.innova.no
5.2 Technical data
5.2.1 Subsea Canister Aluminum
Dimensions: L = 600 mm, Ø = 220 mm (Ø = 210mm in centre)
Depth rating: 3000 m
Supply voltage: 85-260VAC, 50-60Hz
120-370VDC
Maximum power consumption: 1200W
Minimum power consumption: 150W
Recommended fuse: 16A (@110VAC)
Maximum inrush current: 40A (@265V
RMS,
Cold start)
Housing material: Aluminium 6082-T6, hard anodized
Weight in air: 35 kg
Weight in water: 13 kg
5.2.2 Subsea Canister titanium rev. 1
Dimensions: L = 600 mm, Ø = 220 mm (Ø = 210mm in centre)
Depth rating: 3000 m
Supply voltage: 85-260VAC, 50-60Hz
120-370VDC
Maximum power consumption: 1200W
Minimum power consumption: 150W
Recommended fuse: 16A (@110VAC)
Maximum inrush current: 40A (@265V
RMS,
Cold start)
Housing material: Titanium grade 5
Weight in air: 50 kg
Weight in water: 28 kg
