6 Appendix A
Interface Details
6.1 POWER– Input power
Seacon 5506-2006
PIN
FUNCTION
1
Protective Earth
2
Protective Earth
3
110/230VAC-L1
4
110/230VAC-L1
5
110/230VAC-L2
6
110/230VAC-L2
Recommended mates for Seacon 5506-2006: Seacon 55A1-2006 or Seacon 5501-2006.
