Innova MATRIX MK II+ User Manual

Innova – Matrix MK II+
Operation and Maintenance Manual
Date
12.12.2017
Page
31 of 74
Project No.:
604653
Document No.:
MAN-000015294
Rev.
5
P.O. BOX 390 Tel.: +47 51 96 17 00 post@innova.no
4067 Stavanger, Norway Fax.: +47 51 96 17 01 www.innova.no
Ethernet channels overview:
Channel
Connector output
Function
Speed
1
C1
MBE 1
1Gbps
2
C2
MBE 2
1Gbps
3
C3 and C9
Multi-port (via switch)
2 off 100Mbps on C3
1 off 100Mbps on C9
4
N/A
Not In Use
N/A
Table 2
Digital video channels overview (optional):
Channel
Connector output
Function
1
C4
DV camera 1
2
C5
DV camera 2
3
C6
DV camera 3
4
N/A
Not in use
Table 3
Analoge video channels overview (optional):
Channel
Connector output
Function
1
C4
AV camera 1
2
C5
AV camera 2
3
C6
AV camera 3
4
N/A
Not in use
5
N/A
Not in use
6
N/A
Not in use
Table 4

Innova MATRIX MK II+ Specifications

General

Brand	Innova
Model	MATRIX MK II+
Category	Diagnostic Equipment
Language	English
