Innova – Matrix MK II+
Operation and Maintenance Manual
Date
12.12.2017
Page
21 of 74
Project No.:
604653
MAN-000015294
Rev.
5
P.O. BOX 390 Tel.: +47 51 96 17 00 post@innova.no
4067 Stavanger, Norway Fax.: +47 51 96 17 01 www.innova.no
4.6 Troubleshooting
Fault description
Reason
Fix
RS232 or RS485 on combined
port does not work.
Wrong setting
Check settings on Edit screen.
See chapter 3.4.3
Wrong pinout topside
Pinout for RS232 and RS385
are differnet topside. Check
Chapter 6 for pinout
Ethernet through the fiber link
is not working.
Mismatching baudrates
C1 and C2 are set to 1 Gbps.
If a 100 mbit device is to be
connected t subsea the topside
jumper needs to set to ON.
If an ethernet switch is to be
used on output 3 on the
topside, it has to be 1 Gbps
capable.
Fuses in the bottle blows for
no apperant reason.
Fuses set to low.
Check settings on Edit screen.
See chapter 3.4.3
Some equimpent has pulsating
load which confuses the fuses.
Set the DRIVER FAULT
CONFIG. Setting to ON
See chapter 3.4.3
CAUTION: This will auto-
reset the fuses if they are
blown.
Power on C12 is missing even
when powered on.
Fuse is blown
Replace fuses on Matrix
controller board. Glass fuse
3,15A
Outputs are still ON after loss
of communitaction or after
power down of topside.
KEEP setting set in software.
Goto the EDIT section of the
CONTROL screen of the
topside and set output to
RESET.
See chapter 3.4.3
Outputs are turned off by
themselves.
RESET setting set in software
and loss off communication.
Goto the EDIT section of the
CONTROL screen of the
topside and set output to
RESET.
See chapter 3.4.3
ALARM LED is Green
Update of firmware complete
Power cycle the topside unit.
