Schematic Signal Name Pin Number I/O Standard Description
FM_A15 C15 1.8 V FM address bus
FM_A16 H3 1.8 V FM address bus
FM_A17 H2 1.8 V FM address bus
FM_A18 E13 1.8 V FM address bus
FM_A19 F13 1.8 V FM address bus
FM_A20 G13 1.8 V FM address bus
FM_A21 G12 1.8 V FM address bus
FM_A22 E12 1.8 V FM address bus
FM_A23 J13 1.8 V FM address bus
FM_A24 G5 1.8 V FM address bus
FM_A25 H13 1.8 V FM address bus
FM_A26 H4 1.8 V FM address bus
FM_D0 J15 1.8 V FM data bus
FM_D1 L16 1.8 V FM data bus
FM_D2 L14 1.8 V FM data bus
FM_D3 K14 1.8 V FM data bus
FM_D4 L13 1.8 V FM data bus
FM_D5 L15 1.8 V FM data bus
FM_D6 M15 1.8 V FM data bus
FM_D7 M16 1.8 V FM data bus
FM_D8 K16 1.8 V FM data bus
FM_D9 K15 1.8 V FM data bus
FM_D10 J14 1.8 V FM data bus
FM_D11 K13 1.8 V FM data bus
FM_D12 L12 1.8 V FM data bus
FM_D13 N16 1.8 V FM data bus
FM_D14 M13 1.8 V FM data bus
FM_D15 L11 1.8 V FM data bus
FM_D16 E4 1.8 V FM data bus
FM_D17 F6 1.8 V FM data bus
FM_D18 F4 1.8 V FM data bus
FM_D19 C2 1.8 V FM data bus
FM_D20 D1 1.8 V FM data bus
FM_D21 F1 1.8 V FM data bus
FM_D22 E3 1.8 V FM data bus
FM_D23 G2 1.8 V FM data bus
continued...
6. Board Components
683526 | 2023.07.12
Send Feedback
Intel
®
Arria
®
10 FPGA Development Kit User Guide
61
