Intel Arria 10 FPGA User Manual

Schematic Signal Name Pin Number I/O Standard Description
FM_D24 E5 1.8 V FM data bus
FM_D25 C3 1.8 V FM data bus
FM_D26 D3 1.8 V FM data bus
FM_D27 D2 1.8 V FM data bus
FM_D28 E1 1.8 V FM data bus
FM_D29 G3 1.8 V FM data bus
FM_D30 F3 1.8 V FM data bus
FM_D31 F2 1.8 V FM data bus
FMCA_C2M_PG R16 1.8 V FMC port A power good
output
FMCA_PRSNTN G1 1.8 V Green LED. Illuminates when
the FMC port has a board or
cable plugged-in. Driven by
the add-in card.
FMCB_C2M_PG L5 1.8 V FMC port B power good
output
FMCB_PRSNTN E2 1.8 V Green LED. Illuminates when
the FMC port has a board or
cable plugged-in. Driven by
the add-in card.
FPGA_CONF_DONE K1 1.8 V FPGA configuration done LED
FPGA_CONFIG_D0 R1 1.8 V FPGA configuration data
FPGA_CONFIG_D1 T2 1.8 V FPGA configuration data
FPGA_CONFIG_D2 N6 1.8 V FPGA configuration data
FPGA_CONFIG_D3 N5 1.8 V FPGA configuration data
FPGA_CONFIG_D4 N7 1.8 V FPGA configuration data
FPGA_CONFIG_D5 N8 1.8 V FPGA configuration data
FPGA_CONFIG_D6 M12 1.8 V FPGA configuration data
FPGA_CONFIG_D7 T13 1.8 V FPGA configuration data
FPGA_CONFIG_D8 T15 1.8 V FPGA configuration data
FPGA_CONFIG_D9 R13 1.8 V FPGA configuration data
FPGA_CONFIG_D10 P4 1.8 V FPGA configuration data
FPGA_CONFIG_D11 R3 1.8 V FPGA configuration data
FPGA_CONFIG_D12 T10 1.8 V FPGA configuration data
FPGA_CONFIG_D13 P5 1.8 V FPGA configuration data
FPGA_CONFIG_D14 R4 1.8 V FPGA configuration data
FPGA_CONFIG_D15 R5 1.8 V FPGA configuration data
FPGA_CONFIG_D16 M8 1.8 V FPGA configuration data
FPGA_CONFIG_D17 M7 1.8 V FPGA configuration data
FPGA_CONFIG_D18 T5 1.8 V FPGA configuration data
continued...
6. Board Components
683526 | 2023.07.12
Intel
®
Arria
®
10 FPGA Development Kit User Guide
Send Feedback
62
