Intel Arria 10 FPGA User Manual

FMCB Connector Pin
Number
Schematic Signal Name FPGA Pin
Number
I/O Standard
G3 FMCB_CLK_M2C_N1 G17 High Speed Differential
I/O
H4 FMCB_CLK_M2C_P0 J12 High Speed Differential
I/O
G2 FMCB_CLK_M2C_P1 F17 High Speed Differential
I/O
C3 FMCB_DP_C2M_N0 AB2 High Speed Differential
I/O
A23 FMCB_DP_C2M_N1 Y2 High Speed Differential
I/O
A27 FMCB_DP_C2M_N2 V2 High Speed Differential
I/O
A31 FMCB_DP_C2M_N3 T2 High Speed Differential
I/O
A35 FMCB_DP_C2M_N4 P2 High Speed Differential
I/O
A39 FMCB_DP_C2M_N5 M2 High Speed Differential
I/O
B37 FMCB_DP_C2M_N6 K2 High Speed Differential
I/O
B33 FMCB_DP_C2M_N7 J4 High Speed Differential
I/O
B29 FMCB_DP_C2M_N8 H2 High Speed Differential
I/O
B25 FMCB_DP_C2M_N9 G4 High Speed Differential
I/O
K23 FMCB_DP_C2M_N10 F2 High Speed Differential
I/O
K26 FMCB_DP_C2M_N11 E4 High Speed Differential
I/O
K29 FMCB_DP_C2M_N12 D2 High Speed Differential
I/O
K32 FMCB_DP_C2M_N13 C4 High Speed Differential
I/O
K35 FMCB_DP_C2M_N14 B2 High Speed Differential
I/O
K38 FMCB_DP_C2M_N15 A4 High Speed Differential
I/O
C2 FMCB_DP_C2M_P0 AB1 High Speed Differential
I/O
A22 FMCB_DP_C2M_P1 Y1 High Speed Differential
I/O
A26 FMCB_DP_C2M_P2 V1 High Speed Differential
I/O
A30 FMCB_DP_C2M_P3 T1 High Speed Differential
I/O
continued...
6. Board Components
683526 | 2023.07.12
Intel
®
Arria
®
10 FPGA Development Kit User Guide
Send Feedback
92
