Intel Arria 10 FPGA

FMCB Connector Pin
Number
Schematic Signal Name FPGA Pin
Number
I/O Standard
A34 FMCB_DP_C2M_P4 P1 High Speed Differential
I/O
A38 FMCB_DP_C2M_P5 M1 High Speed Differential
I/O
B36 FMCB_DP_C2M_P6 K12 High Speed Differential
I/O
B32 FMCB_DP_C2M_P7 J3 High Speed Differential
I/O
B28 FMCB_DP_C2M_P8 H1 High Speed Differential
I/O
B24 FMCB_DP_C2M_P9 G3 High Speed Differential
I/O
K22 FMCB_DP_C2M_P10 F1 High Speed Differential
I/O
K25 FMCB_DP_C2M_P11 E3 High Speed Differential
I/O
K28 FMCB_DP_C2M_P12 D1 High Speed Differential
I/O
K31 FMCB_DP_C2M_P13 C3 High Speed Differential
I/O
K34 FMCB_DP_C2M_P14 B1 High Speed Differential
I/O
K37 FMCB_DP_C2M_P15 A3 High Speed Differential
I/O
C7 FMCB_DP_M2C_N0 AA4 High Speed Differential
I/O
A3 FMCB_DP_M2C_N1 W4 High Speed Differential
I/O
A7 FMCB_DP_M2C_N2 Y6 High Speed Differential
I/O
A11 FMCB_DP_M2C_N3 V6 High Speed Differential
I/O
A15 FMCB_DP_M2C_N4 U4 High Speed Differential
I/O
A19 FMCB_DP_M2C_N5 T6 High Speed Differential
I/O
B17 FMCB_DP_M2C_N6 R4 High Speed Differential
I/O
B13 FMCB_DP_M2C_N7 P6 High Speed Differential
I/O
B9 FMCB_DP_M2C_N8 N4 High Speed Differential
I/O
B5 FMCB_DP_M2C_N9 M6 High Speed Differential
I/O
K5 FMCB_DP_M2C_N10 L4 High Speed Differential
I/O
continued...
6. Board Components
683526 | 2023.07.12
Send Feedback
Intel
®
Arria
®
10 FPGA Development Kit User Guide
93
