Intel Arria 10 FPGA User Manual

FMCB Connector Pin
Number
Schematic Signal Name FPGA Pin
Number
I/O Standard
K8 FMCB_DP_M2C_N11 K6 High Speed Differential
I/O
K11 FMCB_DP_M2C_N12 H6 High Speed Differential
I/O
K14 FMCB_DP_M2C_N13 G8 High Speed Differential
I/O
K17 FMCB_DP_M2C_N14 F6 High Speed Differential
I/O
K20 FMCB_DP_M2C_N15 E8 High Speed Differential
I/O
C6 FMCB_DP_M2C_P0 AA3 High Speed Differential
I/O
A2 FMCB_DP_M2C_P1 W3 High Speed Differential
I/O
A6 FMCB_DP_M2C_P2 Y5 High Speed Differential
I/O
A10 FMCB_DP_M2C_P3 V5 High Speed Differential
I/O
A14 FMCB_DP_M2C_P4 U3 High Speed Differential
I/O
A18 FMCB_DP_M2C_P5 T5 High Speed Differential
I/O
B16 FMCB_DP_M2C_P6 R3 High Speed Differential
I/O
B12 FMCB_DP_M2C_P7 P5 High Speed Differential
I/O
B8 FMCB_DP_M2C_P8 N3 High Speed Differential
I/O
B4 FMCB_DP_M2C_P9 M5 High Speed Differential
I/O
K4 FMCB_DP_M2C_P10 L3 High Speed Differential
I/O
K7 FMCB_DP_M2C_P11 K5 High Speed Differential
I/O
K10 FMCB_DP_M2C_P12 H5 High Speed Differential
I/O
K13 FMCB_DP_M2C_P13 G7 High Speed Differential
I/O
K16 FMCB_DP_M2C_P14 F5 High Speed Differential
I/O
K19 FMCB_DP_M2C_P15 E7 High Speed Differential
I/O
C34 FMCB_GA0 K22 1.8 V
D35 FMCB_GA1 L22 1.8 V
D5 FMCB_GBTCLK_M2C_N0 W7 LVDS
continued...
6. Board Components
683526 | 2023.07.12
Intel
®
Arria
®
10 FPGA Development Kit User Guide
Send Feedback
94
