Intel Arria 10 FPGA User Manual

FMCB Connector Pin
Number
Schematic Signal Name FPGA Pin
Number
I/O Standard
B21 FMCB_GBTCLK_M2C_N1 U7 LVDS
D4 FMCB_GBTCLK_M2C_P0 W8 LVDS
B20 FMCB_GBTCLK_M2C_P1 U8 LVDS
D34 FMCB_JTAG_RST — LVDS
D29 FMCB_JTAG_TCK — LVDS
D30 FMCB_JTAG_TDI — LVDS
D31 FMCB_JTAG_TDO — LVDS
D33 FMCB_JTAG_TMS — LVDS
G7 FMCB_LA_RX_CLK_N0 C10 LVDS
D9 FMCB_LA_RX_CLK_N1 F18 LVDS
G6 FMCB_LA_RX_CLK_P0 C11 LVDS
D8 FMCB_LA_RX_CLK_P1 G18 LVDS
G10 FMCB_LA_RX_N0 D16 LVDS
C11 FMCB_LA_RX_N1 H21 LVDS
G13 FMCB_LA_RX_N2 B13 LVDS
C15 FMCB_LA_RX_N3 B18 LVDS
G16 FMCB_LA_RX_N4 D11 LVDS
C19 FMCB_LA_RX_N5 C16 LVDS
G19 FMCB_LA_RX_N6 F12 LVDS
C23 FMCB_LA_RX_N7 G12 LVDS
G22 FMCB_LA_RX_N8 G20 LVDS
G25 FMCB_LA_RX_N9 H18 LVDS
G28 FMCB_LA_RX_N10 L13 LVDS
C27 FMCB_LA_RX_N11 J14 LVDS
G31 FMCB_LA_RX_N12 M17 LVDS
G34 FMCB_LA_RX_N13 M18 LVDS
G37 FMCB_LA_RX_N14 M20 LVDS
G9 FMCB_LA_RX_P0 D17 LVDS
C10 FMCB_LA_RX_P1 G21 LVDS
G12 FMCB_LA_RX_P2 A13 LVDS
C14 FMCB_LA_RX_P3 A18 LVDS
G15 FMCB_LA_RX_P4 D12 LVDS
C18 FMCB_LA_RX_P5 B16 LVDS
G18 FMCB_LA_RX_P6 E12 LVDS
C22 FMCB_LA_RX_P7 G11 LVDS
continued...
6. Board Components
683526 | 2023.07.12
Send Feedback
Intel
®
Arria
®
10 FPGA Development Kit User Guide
95
