Intel Arria 10 FPGA User Manual

FMCB Connector Pin
Number
Schematic Signal Name FPGA Pin
Number
I/O Standard
G21 FMCB_LA_RX_P8 H20 LVDS
G24 FMCB_LA_RX_P9 H19 LVDS
G27 FMCB_LA_RX_P10 M12 LVDS
C26 FMCB_LA_RX_P11 K14 LVDS
G30 FMCB_LA_RX_P12 M16 LVDS
G33 FMCB_LA_RX_P13 L18 LVDS
G36 FMCB_LA_RX_P14 M21 LVDS
H8 FMCB_LA_TX_N0 B17 LVDS
H11 FMCB_LA_TX_N1 B15 LVDS
D12 FMCB_LA_TX_N2 K19 LVDS
H14 FMCB_LA_TX_N3 C13 LVDS
D15 FMCB_LA_TX_N4 A14 LVDS
H17 FMCB_LA_TX_N5 E10 LVDS
D18 FMCB_LA_TX_N6 A12 LVDS
H20 FMCB_LA_TX_N7 F10 LVDS
D21 FMCB_LA_TX_N8 G13 LVDS
H23 FMCB_LA_TX_N9 H10 LVDS
H26 FMCB_LA_TX_N10 K17 LVDS
D24 FMCB_LA_TX_N11 J13 LVDS
H29 FMCB_LA_TX_N12 L14 LVDS
D27 FMCB_LA_TX_N13 N13 LVDS
H32 FMCB_LA_TX_N14 L19 LVDS
H35 FMCB_LA_TX_N15 K21 LVDS
H38 FMCB_LA_TX_N16 J21 LVDS
H7 FMCB_LA_TX_P0 A17 LVDS
H10 FMCB_LA_TX_P1 C15 LVDS
D11 FMCB_LA_TX_P2 J19 LVDS
H13 FMCB_LA_TX_P3 D13 LVDS
D14 FMCB_LA_TX_P4 A15 LVDS
H16 FMCB_LA_TX_P5 E11 LVDS
D17 FMCB_LA_TX_P6 B12 LVDS
H19 FMCB_LA_TX_P7 G10 LVDS
D20 FMCB_LA_TX_P8 F13 LVDS
H22 FMCB_LA_TX_P9 H11 LVDS
H25 FMCB_LA_TX_P10 K16 LVDS
continued...
6. Board Components
683526 | 2023.07.12
Intel
®
Arria
®
10 FPGA Development Kit User Guide
Send Feedback
96
