Intel Core 2 Duo Processor User Manual

Getting Started
Document Number: 320249-001
2 Getting Started
This chapter identifies the development kit’s key components, features and
specifications. It also details basic development board setup and operation.
2.1 Overview
The development board consists of a baseboard populated with the Intel
®
Core
TM
2
Duo processor, the Intel
®
GM45 Express Chipset, other system board components and
peripheral connectors.
2.2 Development Kit Contents
The following hardware, software and documentation is included in the development
kit. Check for damage that may have occurred during shipment. Contact your sales
representative if any items are missing or damaged.
• Letter to the Customer
• Development Kit User’s Manual (this document)
• Software CD-ROM, which includes (see the readme.txt file for a complete list of
CD-ROM contents):
⎯ Embedded system BIOS
⎯ BIOS installation utilities
⎯ Chipset drivers
⎯ Intel Embedded Graphics Drivers
⎯ Intel
®
Active Management Technology (AMT) software installation kit
• Pre-assembled development system, which includes:
⎯ Silver Cascade development board
⎯ Plexiglass stand with Acrylic pad
⎯ Mounting screws and standoffs (installed)
⎯ Intel
®
Core
TM
2 Duo processor with 4 MB L2 Cache on 65nm process in the
478 pin Flip-Chip Pin Grid Array (Micro-FCPGA) package (Installed)
⎯ Processor thermal solution and CPU back plate
⎯ Intel
®
GM45 Express Chipset Graphics and Memory Controller Hub (GMCH)
⎯ GMCH (GM45) heatsink
⎯ I/O Controller Hub 9M (ICH9M)
⎯ Type 2032, 3 V lithium coin cell battery
⎯ One 512 MByte, 200 Pin, DDR3 SO-DIMM
⎯ Port 80 display card
⎯ Power Supply
⎯ 80 GByte SATA Hard Disk Drive
⎯ DVD-ROM Drive
⎯ Disk Drive Power and SATA Cables
• One HDMI and Display Port add-in card (codename Eaglemont)
• One PCI Extension Card (codename Thimble Peak 2)
• One AC to DC Power Adapter

Intel Core 2 Duo Processor Specifications

General

Number of Cores	2
Manufacturing Process	65nm or 45nm (depending on model)
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
L2 Cache	2MB, 4MB, or 6MB (depending on model)
Front Side Bus	1066 MHz
Thermal Design Power (TDP)	35W - 65W (depending on model)
Socket Type	LGA775
Clock Speed	1.6 GHz - 3.33 GHz (depending on model)
Instruction Set	x86, x86-64
Virtualization Technology	Yes (depending on model)
Architecture	Intel Core Microarchitecture
