Getting Started
Development Kit User’s Manual 21
Powering up the board:
1. Switch the power supply on (1) at the switch on the rear of the supply.
2. Press the power button located at SW1C1.
3. As the system boots, press F2 to enter the BIOS setup screen.
4. Check time, date, and configuration settings. The default settings should be
sufficient for most users.
5. Insert an operating system installation disk into the optical drive.
6. Press F10 to save and exit the BIOS setup.
7. The system reboots begins to install the operating system from the optical drive.
Note: An operating system disk is not included in this kit and operating system installation
will not be covered in this User Manual.
2.6.1 Using the AC to DC Power Supply (Mobile Power Mode)
There are a few limitations to development board operation when using the AC to DC
power adapter (mobile power mode).
First, do not mix mobile and desktop power configurations. Unplug the ATX power
supply from connector J4J1 before plugging in the AC to DC Power Adapter to
connector J1G9.
Second, desktop peripherals, including add-in cards, will not work when the board is
powered by the AC to DC power adapter or a battery (mobile power mode). If desktop
peripherals are used, the development board must be powered using the included ATX
power supply (desktop power mode).
Warning: Do not mix mobile and desktop power configurations. Unplug the ATX power supply
from connector J4J1 before plugging in the AC to DC Power Adapter to connector J1G9, or a
battery (not included) to connector J1H1-J1H2
Warning: The power supply cord is the main disconnect device from main AC power. The power
outlet shall be installed near the equipment and shall be readily accessible.
