Table 24. Mott Canyon 4 Configuration Jumper/Switches Settings
#
Description Default Setting Optional Setting Reference
Designator
1
ACZ_SD_0 Destination
(MDC-0-1-2)
1-2 for MDC0 codec A
3-4 for MDC0 codec B
5-6 for MDC1 codec A
7-8 for MDC1 codec B
9-10 for MDC2 codec A
J27
2
ACZ_SD_1 Destination
(MDC-0-1-2)
5-6 for MDC1 codec A
1-2 for MDC0 codec A
3-4 for MDC0 codec B
7-8 for MDC1 codec B
9-10 for MDC2 codec A
J28
3
ACZ_SD_2 Destination
(MDC-0-1-2)
9-10 for MDC2 codec A
1-2 for MDC0 codec A
3-4 for MDC0 codec B
5-6 for MDC1 codec A
7-8 for MDC1 codec B
J29
4 MDC0 Primary Jumper 1-2 for secondary 2-3 for primary J16
5 MDC1 Primary Jumper 1-2 for secondary 2-3 for primary J25
6 3.3V Power Option 1-2 for mobile 2-3 for desktop J24
7 5.0V Power Option 2-3 for desktop 1-2 for mobile J32
8
MDC0 Docking Emulation
(Switch Enable)
1-2 for OFF 2-3 for ON J33
9
MDC0 Docking Emulation
(DOCK_RST#)
1-2 for Normal
2-3 for Docking
Emulation
J26

Intel Core 2 Duo Processor Specifications

General

Number of Cores	2
Manufacturing Process	65nm or 45nm (depending on model)
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
L2 Cache	2MB, 4MB, or 6MB (depending on model)
Front Side Bus	1066 MHz
Thermal Design Power (TDP)	35W - 65W (depending on model)
Socket Type	LGA775
Clock Speed	1.6 GHz - 3.33 GHz (depending on model)
Instruction Set	x86, x86-64
Virtualization Technology	Yes (depending on model)
Architecture	Intel Core Microarchitecture
