Intel Core 2 Duo Processor User Manual

Development Board Physical Reference
Development Kit User’s Manual 55
4.6 LEDs
The following LEDs provide status of various functions on the development board.
Table 21. LEDs
Function Reference Designator
Keyboard number lock CR9G1
Keyboard scroll lock CR9G3
Keyboard caps lock CR9G2
System State S0 CR5H4
System State S3 CR5H6
System State S4 CR5H7
System State S5 CR5H5
System State M0/M1 CR5H3
SATA Activity CR7H1
VID Setting 0 CR1B1
VID Setting 1 CR1B2
VID Setting 2 CR1B3
VID Setting 3 CR1B4
VID Setting 4 CR1B5
VID Setting 5 CR1B6
VID Setting 6 CR1B7
System Power Good CR7H3
LT Status CR8G1

Intel Core 2 Duo Processor Specifications

General

Number of Cores	2
Manufacturing Process	65nm or 45nm (depending on model)
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
L2 Cache	2MB, 4MB, or 6MB (depending on model)
Front Side Bus	1066 MHz
Thermal Design Power (TDP)	35W - 65W (depending on model)
Socket Type	LGA775
Clock Speed	1.6 GHz - 3.33 GHz (depending on model)
Instruction Set	x86, x86-64
Virtualization Technology	Yes (depending on model)
Architecture	Intel Core Microarchitecture
