Intel Core 2 Duo Processor User Manual

Development Board Physical Reference
Development Kit User’s Manual 57
Table 22. H8 Programming Jumpers
# Jumper Reference
Designator
Default Stuffing
Option
Programming Stuffing
Option
1
Remote H8
Programming
J7A1
J8B2
1-2 – normal
operation
2-3 – link the Host Unit to On
Board H8
2
Boot Block
Programming
J9G2
1-2 (IN) – normal
operation
OUT – set SMC_INIT_CLK high
(to program H8)
3 1Hz clock J9H1
OUT – normal
operation, clock
enabled
IN – clock disabled, enable H8
programming
4.7.2 Sideband and Test Headers
Additional sideband and test headers are located on sheet 46 of the Silver Cascade
schematics.
§

Intel Core 2 Duo Processor Specifications

General

Number of Cores	2
Manufacturing Process	65nm or 45nm (depending on model)
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
L2 Cache	2MB, 4MB, or 6MB (depending on model)
Front Side Bus	1066 MHz
Thermal Design Power (TDP)	35W - 65W (depending on model)
Socket Type	LGA775
Clock Speed	1.6 GHz - 3.33 GHz (depending on model)
Instruction Set	x86, x86-64
Virtualization Technology	Yes (depending on model)
Architecture	Intel Core Microarchitecture
