Intel Core 2 Duo Processor User Manual

Add-In Cards
70 Development Kit User’s Manual
Table 26. Board Rework to Support Display Port on Saddlestring
STUFF UNSTUFF BOM Description
C6C11
CAPC,X5R,0402,10V,10%,0.1uF.
IPN : A36096-043 To disconnect TX11# from MCH to PEG
C6C13
CAPC,X5R,0402,10V,10%,0.1uF.
IPN : A36096-044 To disconnect TX11 from MCH to PEG
C6C15
CAPC,X5R,0402,10V,10%,0.1uF.
IPN : A36096-045 To disconnect TX10# from MCH to PEG
C6C18
CAPC,X5R,0402,10V,10%,0.1uF.
IPN : A36096-046 To disconnect TX10 from MCH to PEG
C6D2
CAPC,X5R,0402,10V,10%,0.1uF.
IPN : A36096-047 To disconnect TX9# from MCH to PEG
C6D3
CAPC,X5R,0402,10V,10%,0.1uF.
IPN : A36096-048 To disconnect TX9 from MCH to PEG
C6D7
CAPC,X5R,0402,10V,10%,0.1uF.
IPN : A36096-049 To disconnect TX7# from MCH to PEG
C6D9
CAPC,X5R,0402,10V,10%,0.1uF.
IPN : A36096-050 To disconnect TX7 from MCH to PEG
C6C10
CAPC,X5R,0402,10V,10%,0.1uF.
IPN : A36096-051
To route TX11 from Docking connector
to MCH
C6C12
CAPC,X5R,0402,10V,10%,0.1uF.
IPN : A36096-052
To route TX11# from Docking
connector to MCH
C6D6
CAPC,X5R,0402,10V,10%,0.1uF.
IPN : A36096-053
To route TX8 from Docking connector
to MCH
C6D8
CAPC,X5R,0402,10V,10%,0.1uF.
IPN : A36096-054
To route TX8# from Docking connector
to MCH
C6C16
CAPC,X5R,0402,10V,10%,0.1uF.
IPN : A36096-055
To route TX10 from Docking connector
to MCH
C6C17
CAPC,X5R,0402,10V,10%,0.1uF.
IPN : A36096-056
To route TX10# from Docking
connector to MCH
C6D1
CAPC,X5R,0402,10V,10%,0.1uF.
IPN : A36096-057
To route TX9 from Docking connector
to MCH
C6D4
CAPC,X5R,0402,10V,10%,0.1uF.
IPN : A36096-058
To route TX9# from Docking connector
to MCH
R6R1
RESD,0402,5%,1/16W,0
IPN : A93549-001
R6R2
RESD,0402,5%,1/16W,0
IPN : A93549-002
The AUX signals of the Display Port. It
connects to MCH on RX9 and RX9#
respectively.
R6R3
RESD,0402,5%,1/16W,0
IPN : A93549-003
To connect the level translated Hot
Plug Docking (HPD) to MCH
§

Intel Core 2 Duo Processor Specifications

General

Number of Cores	2
Manufacturing Process	65nm or 45nm (depending on model)
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
L2 Cache	2MB, 4MB, or 6MB (depending on model)
Front Side Bus	1066 MHz
Thermal Design Power (TDP)	35W - 65W (depending on model)
Socket Type	LGA775
Clock Speed	1.6 GHz - 3.33 GHz (depending on model)
Instruction Set	x86, x86-64
Virtualization Technology	Yes (depending on model)
Architecture	Intel Core Microarchitecture
