Intel Core 2 Duo Processor User Manual

Development Board Features
Development Kit User’s Manual 45
3.10 Power Supply Usage and Recommendation
Do not use non-Sparkle ATX power supplies. Only use Sparkle ATX Desktop Power
Supplies.
As the Desktop ATX supplies grew to meet the increased power for those
Motherboards, their minimum loading requirements also grew. When you try to run a
mobile platform on it, it may not load the 5.0V rail enough to meet the minimum
loading requirements for it to maintain regulation.
Recommended power 20-pin ATX power supplies include:
• Sparkle Model No. FSP300-60BTVS meets this requirement and is an ATX12V 1.1
Spec (note that this part may be End Of Life)
These 20-pin ATX power supplies may also work if you can't find the above model
number (lower power supplies are probably better):
• Sparkle (SPI) FSP250-60BT, FSB300-60BT, FSB300-60BTV, FSP350, FSP400-
60GN (these supplies work in the lab, although are not checked against spec)
DO NOT use Delta or PowerMan ATX Supplies. You may experience the following
symptoms when using a non-Sparkle supply:
• "post 00"
• Blue Screen reporting driver or device issue when using a desktop PCI graphics
card
• Hanging during boot with PEG or PCI graphics
• PCI video only during boot, but not available after in Windows*.
§

Intel Core 2 Duo Processor Specifications

General

Number of Cores	2
Manufacturing Process	65nm or 45nm (depending on model)
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
L2 Cache	2MB, 4MB, or 6MB (depending on model)
Front Side Bus	1066 MHz
Thermal Design Power (TDP)	35W - 65W (depending on model)
Socket Type	LGA775
Clock Speed	1.6 GHz - 3.33 GHz (depending on model)
Instruction Set	x86, x86-64
Virtualization Technology	Yes (depending on model)
Architecture	Intel Core Microarchitecture
