Intel Core 2 Duo Processor User Manual

Development Board Features
44 Development Kit User’s Manual
Component /
Interface
Voltage
Plane
Supply Rail Reference
Designator
CK505 3.3V +V3.3M VDD_CK505 R5V12
CK505 3.3V +V3.3S +V3.3S_DB800 R7C9
CK505 1.05V +V1.05M +VDDIO_CLK R5V8
LPC 3.3V +V3.3 +V3.3_LPCSLOT R8F1
LPC 5V +V5 +V5_LPCSLOT R8E3
TPM 5V +V5 +V5_R1_TPM R9M1
TPM 3.3V +V3.3S +V3.3S_R1_TPM R9M2
TPM 3.3V +V3.3A +V3.3A_R1_TPM R9A5
SMC 3.3V +V3.3A +V3.3A_KBC R8H8
PS2 5V +V5 +V5_PS2 R1A1
SIO 3.3V +V3.3S +V3.3S_SIO R7T2
IR 3.3V +V3.3S +V3.3S_IR R4M3
USB 5V +V5A +V5A_USBPWR_IN4 R7H15
USB 5V +V5A +V5A_USBPWR_IN3 R3B3
USB 5V +V5A +V5A_USBPWR_IN2 R7H5
USB 5V +V5A +V5A_USBPWR_IN1 R5W15
SPI 3.3V +V3.3M_WOL +V3.3M_SPI R8R1
SATA 3.3V +V3.3S +V3.3S_SATAP0 R8Y1
SATA 5V +V5S +V5S_SATAP0 R8H12
SATA 12V +V12S +V12S_SATAP0 R8W14
SATA 3.3V +V3.3S +V3.3S_SATAP1 R6J3
SATA 5V +V5S +V5S_SATAP1 R4Y4
SATA 12V +V12S +V12S_SATAP1 R4Y3
System Battery +VCHGR_OUT +VBS R1G13 (0.02Ω)
System Battery AMPS_AD+_Q1 +VBS R1H1 (0.007Ω)
System Battery +VBATA 51120_DRVH1_+VBATA R3H18
System Battery +VBATA 51120_DRVH2_+VBATA_Q R3H3
System 3.3V 51120VBST2_LR +V3.3A_MBL R3G5
System 5V 51120_+V5A_MBL_QL +V5A_MBL R3J2
System ATX +V5A +V5_ATX R4J1*
System ATX +V3.3A +V3.3_ATX R4W20*
System ATX +V12_ATX +VBATA R4Y2
System ATX -V12_ATX -V12A R4Y1
System ATX +V5SB_ATX +V5SB_ATXA R5H8

Intel Core 2 Duo Processor Specifications

General

Number of Cores	2
Manufacturing Process	65nm or 45nm (depending on model)
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
L2 Cache	2MB, 4MB, or 6MB (depending on model)
Front Side Bus	1066 MHz
Thermal Design Power (TDP)	35W - 65W (depending on model)
Socket Type	LGA775
Clock Speed	1.6 GHz - 3.33 GHz (depending on model)
Instruction Set	x86, x86-64
Virtualization Technology	Yes (depending on model)
Architecture	Intel Core Microarchitecture
