Development Board Features
Development Kit User’s Manual 43
Component /
Interface
Voltage
Plane
Supply Rail Reference
Designator
ICH 3.3V +V3.3S +V3.3S_VCCPCORE_ICH R7G14
ICH 3.3V +V3.3M_WOL +V3.3M_VCCPAUX R7F2
ICH 3.3V +V3.3S +V3.3S_PCI_ICH R7F4
ICH 3.3V +V3.3S +V3.3S_SATA_ICH R7G9
Memory Battery +VBATA 1.5_VIN R4A4
Memory 0.9 V +V0.9 +V0.75_R R4B11
Memory 1.8V +V1.5 +V1.5_DIMM0 R5C1
Memory 1.8V +V1.5 +V1.5_DIMM1 R5B4
Memory 3.3V +V3.3M +V3.3M_DIMM0 R3C1 (0.022Ω)
Memory 3.3V +V3.3M +V3.3M_DIMM1 R4B13 (0.022Ω)
LAN 3.3V +V3.3M_LAN_SW +V3.3M_LAN R7A2
LAN 1.8V +V1.8_LAN +V1.8_LAN_M R8A11
LAN 1V +V1.0_LAN_M +V1.0_LAN_M_IN R8A3
PCI 12V +V12S +V12S_PCI R8B1
PCI 3.3V +V3.3S +V3.3S_PCI R9D2
PCI 5V +V5S +V5S_PCI R9B2
PCI 5V +V5 +V5_PCI R8B3
PCIe 12V +V12S +V12S_PCIESLOT1 R7N6
PCIe 12V +V12S +V12S_PCIESLOT2 R7C20
PCe 12V +V12S +V12S_PCIESLOT3 R8B2
PCIe 12V +V12S +V12S_PCIESLOT4 R8C4
PCIe 12V +V12S +V12S_PCIESLOT5 R7N2
PCIe 3.3V +V3.3S +V3.3S_PCIESLOT1 R7N5
PCIe 3.3V +V3.3S +V3.3S_PCIESLOT2 R7R1
PCIe 3.3V +V3.3S +V3.3S_PCIESLOT3 R7C1
PCIe 3.3V +V3.3S +V3.3S_PCIESLOT4 R8D2
PCIe 3.3V +V3.3S +V3.3S_PCIESLOT5 R7N4
Audio 1.5 V +V1.5A_HDA_IO +V3.3S_1.5S_HDA_IO R8E8*
Audio 3.3 V +V3.3A +V3.3A_1.5A_HDA_IO R8E7
Panel Bklt 5V +V5S +V5S_LVDS_BKLT R6U20
Panel Bklt Battery +VBAT +VCC_LVDS_BKLT R6F15
Panel LVDS 3.3V +V3.3S/+V5S VDD_VDL R6V2
Panel LVDS 3.3V +V3.3S +V3.3S_LVDS_DDC R6U19*
