Intel Core 2 Duo Processor User Manual

Development Board Features
42 Development Kit User’s Manual
Component /
Interface
Voltage
Plane
Supply Rail Reference
Designator
GMCH VR 1.05 V 51124_LL1_L +V1.05M R4G4
GMCH VR Battery +VBATA 1.05S_VIN R4G3
GMCH 1.05V +V1.05M +VCC_GMCH R5U3
GMCH VCCP
(1.05V)
+V1.05M +VCCP_GMCH R4F5
GMCH 1.05V +V1.05M +V1.05M_PEG_LR R6E3
GMCH 1.05V +V1.05M +VCC_DMI R5D7
GMCH V_GFX
(1.05S)
+VCC_GFXCORE +VGFX_CORE R3F1
GMCH 1.05V +V1.05M_CANTIGA +V1.05M_A_SM_CK R4R2
GMCH 1.05V +V1.05M_CANTIGA +V1.05M_PEGPLL R5T8
GMCH 1.05V +V1.05M_CANTIGA +V1.05M_MCH_PLL R5F12
GMCH 1.05V +V1.05M_CANTIGA V1.05M_MCH_PLL2 R4D6
GMCH 1.05V +V1.05M_CANTIGA +V1.05M_A_SM R4R2
GMCH 1.5V +V1.5S +V1.5S_TVDAC R4U3
GMCH 1.5V +V1.5 +V1.5_DDR3_GMCH R4D1
GMCH 1.8V +V1.8S +V1.8_DLVDS R5F4
GMCH 3.3V +V3.3S +V3.3S_HV R5F1
GMCH 1.5V +V1.5S +VCC_HDA R5U1
GMCH 3.3V +V3.3S_A_TV_CRT_BG +V3.3S_A_DAC_BG R5F5
GMCH 3.3V +V3.3S_A_TV_CRT_BG +V3.3S_A_TV_DAC R4F3
PCIe Gfx 3.3V +V3.3 +V3.3S_PEG R6P2*
PCIe Gfx 3.3V +V3.3S +V3.3S_PEG R6C1
PCIe Gfx Battery +VBATS_S4 +V12S_PEG R6N6*
PCe Gfx Battery +VBATS +V12S_PEG R6N9
ICH 1.05V +V1.05S +V1.05S_ICH R7F5
ICH 1.05V +V1.05S +V1.05S_ICH_IO R6V10
ICH 1.5V +V1.5S +V1.5S_PCIE_R R6G3
ICH 1.5V +V1.5S +V1.5S_SATA_ICH R7G16
ICH 1.5V +V1.5S +V1.5S_USB_ICH R7H1
ICH 3.3V +V3.3S +V3.3S_DMI_ICH R6G6
ICH 3.3V +V3.3S +V3.3S_GLAN_ICH R6U9
ICH 3.3V +V3.3M_WOL +V3.3M_ICH R7U6
ICH 3.3V +V3.3A +V3.3A_ICH R6F9
ICH 3.3V +V3.3A +V3.3A_USB_ICH R7G1

Intel Core 2 Duo Processor Specifications

General

Number of Cores	2
Manufacturing Process	65nm or 45nm (depending on model)
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
L2 Cache	2MB, 4MB, or 6MB (depending on model)
Front Side Bus	1066 MHz
Thermal Design Power (TDP)	35W - 65W (depending on model)
Socket Type	LGA775
Clock Speed	1.6 GHz - 3.33 GHz (depending on model)
Instruction Set	x86, x86-64
Virtualization Technology	Yes (depending on model)
Architecture	Intel Core Microarchitecture
