Development Board Physical Reference
Development Kit User’s Manual 51
Table 18. Configuration Jumpers and Switches Settings
#
Reference
Designator Description
Default
Setting
Optional
Setting
1 J1G1
BSEL2 (Refer to BSEL Jumper Settings
Section 4.3.2 for Setting Changes) 1-2 1-X
2 J1G3
BSEL1 (Refer to BSEL Jumper Settings
Section 4.3.2 for Setting Changes) 1-2 1-X
3 J1G5
BSEL0 (Refer to BSEL Jumper Settings
Section 4.3.2 for Setting Changes) 1-2 1-X
4 J2B2 CPU CORE VID All OPEN (CPU
5 J2G1 Force Shutdown 1-X (Normal Operation)
1-2 Force the board to
shutdown
6 J2H2 GFX CORE VID All OPEN
7 J3C1 CPU thermal sensor 1-2, 3-4
8 J3J2 Power ON Latch 1-X (Normal Operation) 1-2 Latch the power ON
9 J4H1 No ME G3 to M1 support 1-X
1-2 Jump power state from
G3 to M1
10 J4J2 SATA Power Enable
1-2 (Hot plug/removal
supported) 1-X Hot plug not supported
11 J5G1 SRTC RST 1-X (Keep ME RTC registers) 1-2 Clear ME RTC registers
12 J5H2 CMOS Clear 1-X (Normal Operation)
1-2 Clear the contents of
the CMOS
13 J7A1 In-circuit SMC Programming 1-2 (Normal Operation) 2-3 To Program the H8
14 J7E1 SIO Reset 1-2 (Normal Operation)
2-3 To hold the SIO in
RESET
15 J7H1 SATA interlock switch for port0 1-2 (Present) 1-X Removed
16 J7H2 TPM PHYSICAL PRESENCE 1-X (Not Present) 1-2 (Present)
17 J8B1 PM Lan enable 1-2 (LAN Enable) 2-3 LAN Disable
18 J8B2 In-circuit SMC Programming 1-2 (Normal Operation) 2-3 To Program the H8
19 J8C1 SELCETING SPI0 or SPI1 TO BE
PROGRAMMED
1-X (No device selected for
Programming)
1-2 SPI-0 to be
Programmed enabled
2-3 SPI-1 to be
Programmed enabled
20 J8F2 BIOS recovery 1-X (Normal Operation) 1-2 for BIOS recovery
21 J8G1 SV Setup 1-X (Normal Operation) 1-2 SV Setup
22 J8G3 SMC MD2 1-X
1-2 Advanced Single chip
mode
23 J8G4 CRB/SV Detect 1-X (CRB) 1-2 SV
24 J8G5 SMC MD1 1-2 (Normal Operation)
1-X No external
Programming
25 J8G6 KBC disable 1-X (KBC enabled 1-2 KBC disabled
