Intel Core 2 Duo Processor User Manual

Development Board Physical Reference
Development Kit User’s Manual 47
Table 16. Silver Cascade Development Board Components
1 Chipset VR EU5G1 19 SPI flash 1 U8C4 37 Battery B Connector J1H2
2 Trusted Platform
Module
J9A1 20 SMC/KBC J1A1 38 Battery A Connector J1H1
3 82567 LAN
controller
EU8A1 21 Manufacturing Mode
Jumper
J9J1 39 iAMPS connector EU2G1
4 PCI Express Slot 1 J6B1 22 Virtual Battery Switch SW9H3 40 Intel® Core™ 2 Duo
processor T9400
U5E1
5 PCI Express Slot 2 J6D1 23 SATA Direct Connect J8J1 41 VID LEDs CR1B1
CR1B2
CR1B3
CR1B4
CR1B5
CR1B6
CR1B7
6 DB800 Clock Buffer U7C2 24 Front Panel Header J6H5 42 Manual VID Override
Jumper
J2B2
7 PCI Gold-Fingers S9B1 25 SATA Cable Connect J6J3
J6J2
43 Teenah/Cantiga U5E1
8 PCI Express Slot3 J8B3 26 SPI Flash 2 U8C1 44 PCI Express Graphics
Slot
J6B2
9 PCI Express Slot4 J8D1 27 SATA Port1,4 Power
Connector
J5J1 45 DDR3 VR EU4N1
10 PCI Express Slot5 J7B1 28 Debug XDP – CPU J1F1
11 Mott Canyon 4
Header
J9E2
29 Debug XDP – ICH9M J8H2
12 SMSC SIO U7E3 30 LVDS Connector J6F1
13 Keyboard Scan
Matrix
J9E1 31 Front Panel USB J6H4
J6H2
J6J1
14 LPC Docking
Connector
J9E3 32 CK-505 Derivative EU6H1
15 LPC Sideband
Header
J9G1 33 ATX Power Supply
Connector
J4J1
16 LPC Slot J8E1 34 RTC Battery BT5H1
17 eSATA connector J7J1 35 Docking connector J9C2
18 ICH9M U7F1 36 Graphics VR EU3G1

Intel Core 2 Duo Processor Specifications

General

Number of Cores	2
Manufacturing Process	65nm or 45nm (depending on model)
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
L2 Cache	2MB, 4MB, or 6MB (depending on model)
Front Side Bus	1066 MHz
Thermal Design Power (TDP)	35W - 65W (depending on model)
Socket Type	LGA775
Clock Speed	1.6 GHz - 3.33 GHz (depending on model)
Instruction Set	x86, x86-64
Virtualization Technology	Yes (depending on model)
Architecture	Intel Core Microarchitecture
