Intel FALCON 8 Plus

USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2017 Intel Corporation. All rights reserved 149
Selecting
Bounding
Box
and pushing
ENT opens the
following
screen.
This function
is only avail-
able in GPS
Mode. Here
you can define
a specific
height and
radius around
the starting
position to
specify an area
in which the
Intel® Falcon™
8+ UAV is
allowed to
move.
When the UAV
reaches the set
radius or alti-
tude it stops
and will not fly
any further.
By pushing the
RIGHT/ LEFT
arrow buttons
you can switch
between the
settings for
Radius and
Height and
Activate
and
Deactivate.
Pushing ENT
when selected
Radius or
Height high-
lights the field
behind. By
pushing the
RIGHT/ LEFT
arrow buttons
you can mod-
ify the selected
value.
Selecting
Activate/
Deactivate
activates/
deactivates
the function.
Pushing ENT
confirms the
selection and
brings you
back to the
Main Screen.
Table 4.1: Status Display Menu Structure (Continued)
