Error Code
Error Message
Action message
Type
8607
Recovery boot has been initiated.
Note: The Primary BIOS image may be corrupted or the
system may hang during POST. A BIOS update is
required.
Fatal
A100
BIOS ACM Error
Major
A421
PCI component encountered a SERR error
Fatal
A5A0
PCI Express component encountered a PERR error
Minor
A5A1
PCI Express component encountered an SERR error
Fatal
A6A0
DXE Boot Services driver: Not enough memory available
to shadow a Legacy Option ROM.
Disable OpRom at SETUP to save
runtime memory.
Minor
F.1 POST Error Beep Codes
The following table lists the POST error beep codes. Before system video initialization, the BIOS uses these
beep codes to inform users on error conditions. The beep code is followed by a user-visible code on the
POST progress LEDs.
Table 13. POST Error Beep Codes
Beeps
Error Message
POST Progress Code
Description
1 short
USB device action
N/A
Short beep sounded whenever USB device is discovered in POST
or inserted or removed during runtime.
3 short
Memory error
Multiple
System halted because a fatal error related to the memory was
detected.
3 long
and 1
short
CPU mismatch error
E5, E6
System halted because a fatal error related to the CPU
family/core/cache mismatch was detected.
The integrated BMC may generate beep codes upon detection of failure conditions. Beep codes are sounded
each time the problem is discovered, such as on each power-up attempt, but are not sounded continuously.
Codes that are common across all Intel server boards and systems that use same generation chipset are
listed in the following table. Each digit in the code is represented by a sequence of beeps whose count is
equal to the digit.
Table 14. Integrated BMC Beep Codes
Code
Reason for Beep
Associated Sensors
1-5-2-1
No CPUs installed or first CPU socket is empty
CPU Missing Sensor
1-5-2-4
MSID mismatch occurs if a processor is installed into a system
board that has incompatible power capabilities.
MSID Mismatch Sensor
1-5-4-2
DC power unexpectedly lost (power good dropout) – Power unit
sensors report power unit failure offset.
Power fault
1-5-4-4
Power control fault (power good assertion timeout).
Power unit – soft power control failure offset
1-5-1-2
VR Watchdog Timer sensor assertion
VR Watchdog Timer
1-5-1-4
The system does not power on or unexpectedly power off and a
power supply unit (PSU) is present that is an incompatible model
with one or more other PSUs in the system
PS Status
