Intel® Server System M50CYP1UR Family System Integration and Service Guide
98
Table 5. Intel® Optane™ Persistent Memory 200 Series Module Support
Processor Shelf
Intel® Optane™ Persistent Memory 200
Series Capacity (GB)
Speed (MT/s)
Silver 4300 processors
128
256
512
2666
2400
Gold 5300 processors
128
256
512
2933
2666
2400
Gold 6300 Processors
128
256
512
3200
2933
2666
2400
Platinum 8300 processors
128
256
512
3200
2933
2666
2400
Table 6. Standard DDR4 DIMMs Compatible with Intel® Optane™ Persistent Memory 200 Series Module
Type
Ranks per DIMM and
Data Width
DIMM Size (GB)
8 Gb DRAM density
16 Gb DRAM density
RDIMM
(PTH – up to 2933 MT/s)
(SMT – up to 3200 MT/s)
SR x8
N/A
N/A
SR x4
16
32
DR x8
16
32
DR x4
32
64
3DS-RDIMM
(PTH – up to 2933 MT/s)
(SMT – up to 3200 MT/s)
QR x4
N/A
128 (2H)
OR x4
N/A
256 (4H)
LRDIMM
(PTH/SMT – up to 3200 MT/s)
QR x4
64
128
3DS-LRDIMM
(PTH/SMT – up to 3200 MT/s)
QR x4
N/A
N/A
OR x4
N/A
256 (4H)
Note: SR = Single Rank, DR = Dual Rank, QR = Quad Rank, OR = Oct Rank, H = Stack Height, PTH = Plated
Through Hole, SMT = Surface-Mount Technology
