Entry Server Chassis SC5299-E TPS Power Sub-system
Revision 3.1
Intel order number D37594-005
85
2.5.6 Power Connectors
2.5.6.1 Baseboard Power Connector (P1)
Connector housing: 24-Pin Molex* Mini-Fit Jr.
39-01-2245 or equivalent
Contact: Molex Mini-Fit, HCS, Female, Crimp 44476 or equivalent
Table 100. P1 Baseboard Power Connector
Pin Signal 18 AWG Color Pin Signal 18 AWG Color
1* +3.3 VDC Orange 13 +3.3 VDC Orange
3.3V RS Orange (24AWG) 14 -12 VDC Blue
2 +3.3 VDC Orange 15 COM Black
3* COM Black 16 PSON# Green (24AWG)
COM RS Black (24 AWG) 17 COM Black
4* +5 VDC* Red 18 COM Black
5V RS Red (24AWG) 19 COM Black
5 COM Black 20 Reserved N.C.
6 +5 VDC Red 21 +5 VDC Red
7 COM Black 22 +5 VDC Red
8 PWR OK Gray (24 AWG) 23 +5 VDC Red
9 5VSB Purple 24 COM Black
10 +12V3 Yellow
11 +12V3 Yellow
12 +3.3 VDC Orange
* 5V Remote Sense Double Crimped
