Intel SC5299BRP User Manual

Power Sub-system Intel
®
Entry Server Chassis SC5299-E TPS
Revision 3.1
Intel order number D37594-005
88
Table 106. P7 Right-angle Peripheral Power Connector
Pin Signal 18 AWG Color
1 +12V4 Green
2 COM Black
3 COM Black
4 +5 VDC Red
2.5.6.8 Floppy Power Connector (P5)
Connector housing: Amp* 171822-4 or equivalent
Contact: Amp 170204-1 contact or equivalent
Table 107. P5 Floppy Power Connector
Pin Signal 22 AWG Color
1 +5VDC Red
2 COM Black
3 COM Black
4 +12V4 Green
2.5.6.9 Right-angle SATA Power Connector (P12)
Connector housing: JWT* F6002HS0-5P-18 or equivalent
Table 108. P12 Right-angle SATA Power Connector
Pin Signal 18 AWG Color
1 +3.3V Orange
2 COM Black
3 +5VDC Red
4 COM Black
5 +12V4 Green
2.5.6.10 SATA Power Connector (P13)
Connector housing: JWT* A3811H00-5P or equivalent
Contact: JWT A3811TOP-0D or equivalent
